- Ø Linear Spray Unit Programable
- Ø PLC / Touch Screen Control
- Ø Process Parameter
- Ø 100 Program capacity
- Ø Stencil up to 750mmX750mm
- Ø Cleaning & Drying
- Ø Tap Water inlet Control
- Ø Tap Water waste Control
- Ø Rising Bath Capacity 57Lts
- Ø Power :400Vac 3phase + neutral 50Hz
- Ø Machine weight: 360Kg
- Ø Machine Dimension (LxWxH)
- Ø 950X1250X1850mm
- 1. Machine can be used for cleaning SMT adhesive or solder paste stencil.
- 2. All wet-able parts are in Stainless Steel.
- 3. Spray in air with low pressure spraying nozzles with less than 1 bar for cleaning the sensitive screen and stencil.
- 4. Hot Air Knife with blower fans gives maximum efficiency for drying.
- 5. Reciprocating Vertical elevator mechanism mounted with spray arm and air knife.
- 6. Vertical elevator mechanism with adjustable stroke adjustment reduces the processing time.
- 7. Storage up to 99 Cleaning Programs.
- 8. Weekly Timer
- 9. Password Protected.
10. STC fault monitoring and reporting facility.
11. Status Light Tower
PMT Spray Cleanning [916 Kb]
